HS059 H404 Light Type Champion Snatch Block Tail Board

•Material of tail board:Forged super alloy steel with 3:1 safety factor
•Material of pulley: Cast steel
•Material of wheel core: Pure bronze
•Quantity of pulley: Single
•Connecting type: Link type

SKU: 3.03.03

Overview
Contact Us

HS059 H404 Light Type Champion Snatch Block Tail Board
Stock no.	Size in	WLL t	Diam of rope in	Net weight kg
Stock no.	Size in	WLL t	Diam of rope in	Net weight kg
HS3030301	3	2	3/8	1.4
HS3030302	4-1/2	4	1/2	3.8
HS3030303	6	8	3/4	7
HS3030304	8	8	3/4	11
HS3030305	10	8	3/4	16
HS3030306	12	8	3/4	25
HS3030307	14	8	3/4	32
HS3030308	16	15	7/8	48
HS3030309	18	15	1	62
