SINGLE POINT MOORING ROPE

Structure: 8/12 Strand or inner core with jacket
Made of polyamid fiber, inner core with out jacket make the rope has good shock-absorption and abrasion resistance. Put special coating and metal accessory on rope ends and plus oat foam, Production according to OCIMF 2000 Guideline
Specific Gravity:1.14g/cm3
Melting Point: 215°C
Breaking Elongation 15%-28%
Abrasion Resistance:Very Good
Chemical Resistance:Very Good
UV Resistance: Very Good
Floatable
Bespoke diameter and length

SKU: 5.03.07

SINGLE POINT MOORING ROPE
Stock no.	Size (mm)	Circ.(mm)	Weight (g/m)	Single Leg BS (kN)	Grommet BS (kN)
HS5030701	72	226	3330	1196	2033
HS5030702	80	251	4000	1441	2465
HS5030703	88	276	4800	1715	2916
HS5030704	96	301	5740	2029	3465
HS5030705	104	327	6880	2401	4082
HS5030706	112	352	7880	2744	4665
HS5030707	120	377	9290	3185	5415
HS5030708	128	402	10380	3548	6047
HS5030709	136	427	12000	4087	6963
HS5030710	144	452	13320	4508	7664
HS5030711	152	477	14630	4900	8330
HS5030712	160	502	16230	5390	9163
HS5030713	168	528	17900	5929	10079
HS5030714	176	553	19800	6586	11212
HS5030715	180	565	20410	6733	11451
