HSZ-HS626 Series Manual Chain Block

•Working load limit(WLL):0.5-20t(and 30/50t for heavy duty type)
•This block can be used in 360 degrees
•This block is equipped with axletree and can reduce hand pulling force
•Special designed top hook can backout easily and can be installed with trolley directly
•This block is equipped with premium grade alloy load chain and zinc plated hand chain as standard
•This block is equipped with drop forged and expertly heat treated hooks for great strength and long wearing life
•The hooks are fitted with robust safety latches and rotate 360 degrees
•This block can carry overload limiter

SKU: 3.02.01

HSZ-HS626 Series Manual Chain Block
Stock no.	Model	Capacity (t)	Standard lift (m)	Running test load (kn)	Effort required to lift rated load (n)	Diameter of hand chain (mm)	Strands of load chain	Diameter of load chain (mm)	Dimensions (mm)					Net weight (kg)	Extra weight per metre of extra lift (kg)
Stock no.	Model	Capacity (t)	Standard lift (m)	Running test load (kn)	Effort required to lift rated load (n)	Diameter of hand chain (mm)	Strands of load chain	Diameter of load chain (mm)	A	B	C	D	K	Net weight (kg)	Extra weight per metre of extra lift (kg)
HS3020101	U626-0.25t	0.25	2.5	3.75	220	3*15	1	4*12	102	106	260	21	20	3.8	0.37
HS3020102	U626-0.5t	0.5	2.5	7.5	250	5*23.6	1	5*15	132	148	345	35	23	11	1.5
HS3020103	U626-1.0t	1	2.5	15	285	5*23.6	1	6*18	132	148	376	35	23	12.2	1.8
HS3020104	U626-1.5t	1.5	2.5	22.5	380	5*23.6	1	7.1/8*24	173	196	442	45	33	16.5	2.4
HS3020105	U626-2.0t	2	2.5	30	340	5*23.6	1	8*24	175	210	470	50	35	19.5	2.4
HS3020106	U626-3.0t	3	3	45	370	5*23.6	2	7.1/8*24	205	255	548	55	39	24	3.7
HS3020107	U626-5.0t	5	3	75	370	5*23.6	2	9/10*30	189	280	688	65	45	41.1	5.4
HS3020108	U626-10t	10	3	150	380	5*23.6	4	10*30	189	463	765	75	54	78	9.8
HS3020109	U626-15t	15	3	225	380	5*23.6	6	10*30	200	718	900	95	71	135	14.7
HS3020110	U626-20t	20	3	300	390*2	5*23.6	8	10*30	200	840	950	106	82	192	19.6
HS3020111	U626-30t	30	3	450	390*2	5*23.6	12	10*30	350	700	1020	110	85	300	28.5
HS3020112	U626-50t	50	3	750	390*2	5*23.6	22	10*30	430	930	1920	130	130	1120	50.5
