Flemish Eye Steel Swaging Sleeves(S-505)

•Material: High quality Aluminium Alloy
•Production method: Cold Extrusion
Aluminum Ferrules is a kind of pipe joint material for the conclusion of steel wire rope. It is mainly used for pressing and threading the end ring of steel wire rope.

•Material: 99% copper
•Production method: Cold Extrusion
•Haosail Aluminium Oval Sleeves are extruded from a high quality aluminium alloy, and heat treated for excellent cold forming or swaging quality.
•Return eye splice using Haosail Aluminium Oval Sleeves will attain 95% of Improved plow wire rope nominal strength when properly swaged.
•Caution:Return eye slings using oval aluminium sleeves must be properly swaged to attain strength.

•Material: High quality Aluminium Alloy
•Production method: Cold Extrusion
Aluminium Stop Button is a kind of ferrule.It is mainly used for pressing and threading the end ring of steel wire rope. Haosail Aluminum ferrules are made from seamless aluminium material.

•Material: Carbon steel and annealed
•Production method: Forging
•Surface treatment: Self-color/Electric galvanized/Hot dip galvanized •The swage sockets have an efficiency rating of 95% based on the nominal strength of wire rope. •The swage Sockets are recommended for use with 6*19,6*37 ISP or EIP,EEIP,RRL,FC or IWRC wire rope.

•Material: Forged alloy steel to 1-1/2”, and cast alloy steel from 1-5/8” to 4”
•Production method: Forging/Casting
•Surface treatment: Self-color/Electric galvanized/Hot dip galvanized •The spelter socket terminations have an efficiency rating of 100% of the nominal strength of wire rope.
•The sockets are recommended to use with 6*7,6*19 or 6*37, IPS OR XIP,XXIP(EIP),RRL,FC,OR IWRC wire rope.
•Closed Grooved Sockets meet the performance requirements of Federal Specification RR-S-550D,Type B, except for those provisions required by the contractor.

•Material: Forged alloy steel to 1-1/2”, and cast alloy steel from 1-5/8” to 4”
•Production method: Forging/Casting
•Surface treatment: Self-color/Electric galvanized/Hot dip galvanized •The spelter socket terminations have an efficiency rating of 100% of the nominal strength of wire rope.
•The sockets are recommended to use with 6*7,6*19 or 6*37, IPS OR XIP,XXIP(EIP),RRL,FC,OR IWRC wire rope.
•Closed Grooved Sockets meet the performance requirements of Federal Specification RR-S-550D,Type A, except for those provisions required by the contractor.

•Material: Carbon steel
•Production method: Cold Extrusion
•Steel Stop Button is a kind of ferrule.It is mainly used for pressing and threading the end ring of steel wire rope.
