D Shackle with Collar Pin

•Material: Stainless steel 304 or 316
•Production technology: Die Forging--Quenched and Tempered
•Safety factor: 6:1; 4:1
•The proof load is 2 times of Working load limit
•The breaking load is 4 times of Working load limit
•Breakage test is made for samples of each batch.
•100% MPI for crack detection.

SKU: 4.01.01

Overview
Contact Us

D Shackle with Collar Pin
Stock no.	Size(mm)	A(mm)	B(mm)	L(mm)	BL(lbs)
HS4010101	3	3	6	12	400
HS4010102	4	4	8	16	550
HS4010103	5	5	10	20	1000
HS4010104	6	6	12	24	1700
HS4010105	7	7	14	28	2000
HS4010106	8	8	16	32	2800
HS4010107	9	9	18	36	3500
HS4010108	10	10	20	40	4500
HS4010109	12	12	24	48	6000
HS4010110	13	13	26	52	6500
HS4010111	14	14	28	56	7000
HS4010112	16	16	32	64	10000
HS4010113	19	19	38	76	15000
HS4010114	22	22	44	88	19000
HS4010115	25	50	50	100	23000
HS4010116	28	28	56	112	26000
HS4010117	32	32	64	128	38000
