HSCDK-Vertical Plate Clamp

•Material:High quality carbon steel
•Working load limit(WLL): 0.8-30t
•Used for lifting and transporting of thick steel plate and profiled bar in horizontal position
•The screw jaw of the body can be changed through the safety releasing button
•The working load limite is the max load that the clamp are autorized to support when used in pairs with a lift angle of 60°.
•In lifting operations, the clamps should be used in pairs or multiples
•Collision with hung articles is forbidden during the hoisting

•Material:High quality carbon steel
•Working load limit(WLL): 1.0t
•Used for safe lifting and transporting of steel oil drums
•The SL drum clamp can be used singly or in pair
•Equipped with automatic locking mechanism
•Collision with hung articles is forbidden during the hoisting
•Supported by Grade 80 chain sling on 2 legs
•The ideal design of the clamp makes it compact, lightweight and easy to operate

•Material:High quality carbon steel
•Working load limit(WLL): 1.0-10t
•The clamp is fixed on spiral steel pipe to provide a quick and versatile rigging point for hoisting equipment, like pulley blocks
•Lock the spindle counter-clockwise and loosen the clamp opening. Clamp the inferior border of I-steel as the picture. Lock the spindle clockwise to clamp tightly
•The shackle is in whole design with the body
•Overload is forbidden

•Material:High quality carbon steel
•Working load limit(WLL): 0.8-5t
•Used for lifting and transporting of thick steel plate and structures from all positions(horizontal,vertical and sidelong)
•Equipped with articulated lifting shackle
•Clamps are equipped with a safety mechanism, ensuring the clamp not slip when lifting force is applied and when as in open position. The clamp is locked in closed as well as in open position
•Collision with hung articles is forbidden during the hoisting

•Material:High quality carbon steel
•Working load limit(WLL): 0.8-30t
•Used for lifting and transporting of steel plate and structures from all positions(horizontal,vertical and sidelong)
•Equipped with articulated lifting shackle(CD type)
•Clamps are equipped with a safety mechanism, ensuring the clamp not slip when lifting force is applied and when as in open position. The clamp is locked in closed as well as in open position
•Overload is forbidden

•Material:High quality carbon steel
•Working load limit(WLL): 1.5-18t
•Used for horizontal lifting and transporting of steel and concrete pipes
•The clamp must be used in pair in lifting
•The surface of the clamp is applied with special plastic cover
•The plastic cover is easy to change
•The ideal design of the clamp makes it compact, lightweight and high lifting capacity

•Material:High quality carbon steel
•Working load limit(WLL): 0.6t
•Used for lifting and transporting of oil drums where the drums have to stay in a horizontal position
•The drum clamp can be used singly or in pair
•The ideal design of the clamp makes it compact, lightweight and easy to operate
